Yönetilebilir L2 PoE Sviç
(0) Yorum - 0 Puan
Kategori
Stok Kodu
AWB5005
ÖZELLİKLER VE AVANTAJLARI
Full gigabit PoE switch
- - 802.at/af PoE+, 120 W total PoE budget, 30 W per port
- - 8 x gigabit PoE RJ45 ports
- - 2 x gigabit (100/1000M) SFP ports
- - Non-blocking switch fabric (Diğer portlardaki trafiği etkilemeden, boş portların herhangi birinden yönlendirme isteği yapılabilir)
Güvenli ağ işlemleri için Layer 2 yönetimi
- - VLAN, QoS, IGMP Snooping, LACP/Trunk
- - Redundancy için Rapid Spanning Tree (RSTP)
- - GUI, CLI or SNMP üzerinden konfigürasyon
Endüstriyel Uygulamalar İçin Geliştirildi
- - DIN-raya montaj
- - IP31-metal gövde
- - Kompak ve güçlü dizayn
Zorlu Ortamlar İçin Geliştirildi
- - Dual 24VDC booster power giriş (12~57VDC to 54V PoE çıkış)
- - Geniş sıcaklık aralığı, -40°C~70°C
- - Yüksek seviye EMC koruması
TEKNİK ÖZELLİKLER
Ethernet | 8 x 10/100/1000Base-T RJ-45, PoE+ 2 x 100/1000Base SFP, DDM Store and Forward Technology with Non-Blocking Switch Fabric |
Konsol | 1 x RS232 (RJ45) 115200.n.8.1 |
Sıcaklık aralığı | -40°C-70°C , 0%-95% Non- Condensing |
Veri hızı | 1000Base-TX/FX 100Base-TX/FX 10Base-TX/FX |
Güç | 24 VDC (12-57 VDC) Max. 120W@24V~57VDC, Max.60W@12VDC support for dual power supplies |
Ağırlık | 985 g |
Gövde | Çelik/aluminyum |
IP koruma sınıfı | IP31 |
Ölçüler | 58 x 155 x 125 mm (without DIN rail clip) |
Montaj | DIN ray montaj (bracket included) |
Configürasyon | CGI WebGUI, CLI, Telnet, SSH, SNMP |
Güvenlik | IEEE 802.1X/RADIUS, Management IP, Management VLAN, SSL |
Redundancy | Rapid Spanning Tree Protocol/Spanning Tree Protocol (RSTP/STP) |
Trafik Yönetimi | Flow Control, Port Trunk/802.3ad LACP, VLAN, Private VLAN, Shared VLAN, Rate Limiters, Port Mirror, IGMP Snooping v2, Port classification, Port policing, Port scheduler, Port shaping, QoS control list, Storm policing, WRED, Port Security, ACL, Loop Protection |
Ağ Yönetimi | IPv4 management, SNMP v1/v2c/v3/Trap, MIBs, LLDP, DHCP client, TFTP, System Log, NTP |
PoE | IEEE 802.3af/at (PoE/PoE+) |
